Technical Specifications

Tech Package

HOUSE AUDIO SYSTEM

FOH Speaker System

5-way system consisting of (9) JBL VT4886 3-way line array elements + (3) JBL VT4883 2×12” LF elements flown per side and (4) JBL STX828S 2×18” Subwoofers built into sealed isolated chamber inside stage. Sub signal is aux fed from FOH console.

System bandpass as follows:

STX828S: 28Hz – 60Hz (Dual 18” subs under the deck) x 4
VT4883: 60Hz – 120Hz (Dual 12” LF elements flown) x 3 per side
VT4886: 120Hz – 20kHz (3-way full range line array elements) x 9 per side

  • Power and Processing via Crown I-Tech HD amplifiers with V5 Tunings. Continuous power available to the speakers at the connected speaker loads is 64,200 watts.
  • System can produce 100dB(A) Slow at FOH with approximately 15dB of peak amplifier head room remaining.
  • System measures with a gradual 6dB SPL drop from the front row to the back of house.
  • Front Fills consist of (2) Meyer Sound UPJ-1P self-powered speakers-re-tasked from former system. Front fill signal patched to Matrix 24 on console and routed to stage box output K8.   Front fills are aligned and tuned. Processing settings reside in FOH console memory.

FOH Mixing Console

  • Allen & Heath Avantis 64 Channel Input, 42 Bus Digital Mixer
  • Console has 12 faders for inputs (with multiple assignable pages), 12 faders for outputs (with multiple assignable pages). 12 stero FX buses
  • Console I/O:
  • FOH Local I/O – (64) XLR in and (42) XLR out on console
  • Stagebox I/O – (48) XLR in and (16) XLR out

Floor Monitors

  • Floor Monitors:
  • (8) DB Technologies FMX-12 2-Way Active Coaxial Stage Monitors
  • Users can provide preferred monitor wedges and/or in-ear-monitors as needed for event.

Monitor Mixing Console

  • Monitors typically mixed from FOH Console.
  • Users can provide preferred monitor console with active splitter if required for event.

Zone Audio Distribution

Discrete audio distribution feeds can be sent from the FOH tech position to the Green Room, Dressing Room and Lobby as needed.   This includes voice paging with ducking capability and background music applications.

Individual volume and mute control for each zone is possible using the integrated wall controller

Microphone Package

  • 1 x Shure Beta 91a
  • 1 x Shure Beta 52a
  • 4 x Sennheiser 904
  • 6 x Shure SM58 dynamic hand held vocal microphones
  • 7 x Shure SM57 dynamic instrument microphones
  • 2 x Shure SM81 condenser instrument microphones
  • 4 x Shure PGA81 condenser instrument microphones
  • 4 x Shure Beta98 instrument microphones
  • 1 x AKG D112MKII Bass-Drum microphone
  • 2 x Sennheiser e906 dynamic instrument microphones
  • 4 x Countryman active DI boxes
  • 4 x Radial Pro Co passive DI boxes
  • 2 x Radial Pro passive Stereo DI boxes
  • 4 x Shure ULX diversity wireless microphone systems with SM58 microphone capsules
  • 1 x Shure MX410 low profile goose neck microphone for podium
  • Users can provide preferred microphones as required for event.

Users can provide preferred microphones as required for event.

Cables

  • Assorted 15’,20’,25’ and 50’ microphone cables provided upon request.
  • Assorted microphone stands provided upon request.
  • 3 x Elite Core PS Series Box-to-Fan Snakes 12×4 50’
  • 1 – 50’ – 16 channel – 4 returns snake
  • 1 – 50′ – 12 channel snake
  • 1 – 20′ – 8 channel snake
